1140318 meeting

SSSD_CP 儲存庫探勘

發佈於 2025-03-12 更新於 2025-03-17 約 1295 字預計閱讀 3 分鐘次閱讀

前言

在閱讀並測試 SSSD_CP 儲存庫時，由於該 SSSD 分支需要使用 linux 、 conda 及 docker，便先於安裝。因為操作系統為 windows ，故選擇安裝 windows subsystem linux (wsl) 作為操作環境。在測試過程中發現，因 windows 的換行符號為 \r\n ，通稱 CRLF ；但 linux 、 unix 和 mac 等系統用的是 \n 作為換行符號，通稱 LF，故在執行中時，如果經過 windows 系統編輯過的檔案就無法順利於 wsl 中執行（因為多了 \r 導致檔案路徑報錯）。

因此，我們便需要使用 dos2unix 這個 linux 套件將文件、檔案中的換行符號轉換為 linux 可接受的字元，才能運行 .sh 腳本。

執行訓練

以下為採用 mujoco.npy 資料集進行訓練的設定檔案。

model.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
wavenet:
  # WaveNet model parameters
  input_channels: 14  # Number of input channels
  output_channels: 14  # Number of output channels
  residual_layers: 36  # Number of residual layers
  residual_channels: 256  # Number of channels in residual blocks
  skip_channels: 256  # Number of channels in skip connections

  # Diffusion step embedding dimensions
  diffusion_step_embed_dim_input: 128  # Input dimension
  diffusion_step_embed_dim_hidden: 512  # Middle dimension
  diffusion_step_embed_dim_output: 512  # Output dimension

  # Structured State Spaces sequence model (S4) configurations
  s4_max_sequence_length: 100  # Maximum sequence length
  s4_state_dim: 64  # State dimension
  s4_dropout: 0.0  # Dropout rate
  s4_bidirectional: true  # Whether to use bidirectional layers
  s4_use_layer_norm: true  # Whether to use layer normalization

diffusion:
  # Diffusion model parameters
  T: 200  # Number of diffusion steps
  beta_0: 0.0001  # Initial beta value
  beta_T: 0.02  # Final beta value

其中，我只更改 input_channels 和 output_channels 使其輸入與輸出符合資料集的 features 數量。以及更改了 s4_max_sequence_length 以符合時間點。

training.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
# Training configuration
batch_size: 80  # Batch size
output_directory: "/mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/results/checkpoint"  # Output directory for checkpoints and logs
ckpt_iter: "max"  # Checkpoint mode (max or min)
iters_per_ckpt: 1000  # Checkpoint frequency (number of epochs)
iters_per_logging: 1000  # Log frequency (number of iterations)
n_iters: 60000  # Maximum number of iterations
learning_rate: 0.0002  # Learning rate

# Additional training settings
only_generate_missing: true  # Generate missing values only
use_model: 2  # Model to use for training
masking: "forecast"  # Masking strategy for missing values
missing_k: 24  # Number of missing values

# Data paths
data:
  train_path: "/mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/SSSD/datasets/Mujoco/train_mujoco.npy"  # Path to training data

以下是成功執行訓練腳本的提示詞。

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
user@LAPTOP-KOPTLCHM:/mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/SSSD_CP$ conda activate sssd
(sssd) user@LAPTOP-KOPTLCHM:/mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/SSSD_CP$ ./scripts/diffusion/training_job.sh -m configs/model.yaml -t configs/training.yaml
Script is running from: /mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/SSSD_CP/scripts/diffusion
Intializing conda
Activating Conda Env: sssd
[Execution - Training]
/mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/SSSD_CP/scripts/diffusion/train.py --model_config configs/model.yaml --training_config configs/training.yaml
2025-03-16 16:51:31,034 - sssd.utils.logger - INFO - Model spec: {'wavenet': {'input_channels': 14, 'output_channels': 14, 'residual_layers': 36, 'residual_channels': 256, 'skip_channels': 256, 'diffusion_step_embed_dim_input': 128, 'diffusion_step_embed_dim_hidden': 512, 'diffusion_step_embed_dim_output': 512, 's4_max_sequence_length': 100, 's4_state_dim': 64, 's4_dropout': 0.0, 's4_bidirectional': True, 's4_use_layer_norm': True}, 'diffusion': {'T': 200, 'beta_0': 0.0001, 'beta_T': 0.02}}
2025-03-16 16:51:31,034 - sssd.utils.logger - INFO - Training spec: {'batch_size': 80, 'output_directory': '/mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/results/checkpoint', 'ckpt_iter': 'max', 'iters_per_ckpt': 1000, 'iters_per_logging': 1000, 'n_iters': 60000, 'learning_rate': 0.0002, 'only_generate_missing': True, 'use_model': 2, 'masking': 'forecast', 'missing_k': 24, 'data': {'train_path': '/mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/SSSD/datasets/Mujoco/train_mujoco.npy'}}
2025-03-16 16:51:31,190 - sssd.utils.logger - INFO - Using 1 GPUs!
2025-03-16 16:51:31,287 - sssd.utils.logger - INFO - Output directory /mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/results/checkpoint/T200_beta00.0001_betaT0.02
2025-03-16 16:51:42,974 - sssd.utils.logger - INFO - Current time: 2025-03-16 16:51:42
2025-03-16 16:51:44,226 - sssd.utils.logger - INFO - No valid checkpoint model found, start training from initialization.
2025-03-16 16:51:44,227 - sssd.utils.logger - INFO - Start the 1 iteration
  3%|███▌                                                                                                                   | 3/100 [01:46<56:43, 35.09s/it

要注意的是，此專案必須使用 Python 3.10.13 (配合專案內 PyTorch 的版本)，並且要事先安裝 miniconda 以及 docker ，並執行 /envs/conda/build_conda_env.sh 和 /envs/vm/install_on_ubuntu.sh 腳本，以設定執行環境。

請記得在執行前要先進入 conda 的 sssd 環境，否則會報錯。

1
2
3
4
5
(base) user@LAPTOP-KOPTLCHM:/mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/SSSD_CP$ conda deactivate
user@LAPTOP-KOPTLCHM:/mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/SSSD_CP$ ./scripts/diffusion/training_job.sh -m configs/model.yaml -t configs/training.yaml
Script is running from: /mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/SSSD_CP/scripts/diffusion
/mnt/d/Code/sssd_cp_learning_and_testing/learning_and_testing/SSSD_CP/scripts/diffusion/../../envs/conda/utils.sh: line 12: conda: command not found
No Conda environment found matching

提示

如果無法成功執行，或是提示找不到 sssd 模組，建議重新進入 wsl ，並重新進入 conda 的 sssd 環境。

觀察

這裡的 missing_k 表示為

1
missing_k (int): The number of the last elements to be predicted.

觀察 /sssd/core/utils.py 後我們可以發現其中增加了對 missing values 的處理，如下

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
def get_mask_forecast(sample: torch.Tensor, k: int) -> torch.Tensor:
    """
    Get mask of same segments (black-out missing) across channels based on k.

    Args:
        sample (torch.Tensor): Tensor of shape [# of samples, # of channels].
        k (int): Number of missing values.

    Returns:
        torch.Tensor: Mask of sample's shape where 0's indicate missing values to be imputed, and 1's indicate preserved values.
    """
    mask = torch.ones_like(sample)  # Initialize mask with all ones

    # Calculate the indices of missing values
    s_nan = torch.arange(mask.shape[0] - k, mask.shape[0])

    # Apply mask for each channel
    for channel in range(mask.shape[1]):
        mask[s_nan, channel] = 0

    return mask

訓練結果

因單一 iteration 就要訓練一小時(在我的電腦上)，故

https://raw.githubusercontent.com/Josh-test-lab/website-assets-repository/refs/heads/main/posts/1140318%20meeting/To%20be%20continued.jpg — 下集待續

運行環境

作業系統：Windows 11 24H2
子系統：Windows subsystem Linux (Ubuntu)
Miniconda
Docker
CUDA 12.8 driver (Running version 12.1 in code)
程式語言：Python 3.10.13 for Linux

延伸學習

我測試此項目的 Github 儲存庫。

參考資料

Juan Lopez Alcaraz 、 Nils Strodthoff（2022）。Diffusion-based time series imputation and forecasting with structured state space models。Transactions on Machine Learning Research。參考自 https://openreview.net/forum?id=hHiIbk7ApW
SSSD（2022）。GitHub。參考自 https://github.com/AI4HealthUOL/SSSD
SSSD_CP（2024）。GitHub。參考自 https://github.com/egpivo/SSSD_CP
