Title: 載入資料並測試 dart 的 TSMixer 模型
Author: Hsu, Yao-Chih
Version: 1140804
Reference:
"""
# import modules
import os
import numpy as np
import pandas as pd
import xarray as xr
from tqdm import tqdm
import matplotlib.pyplot as plt
import csv
import cartopy.crs as ccrs
import cartopy.feature as cfeature
# functions
def check_data_folder(folder):
return os.path.exists(folder) and os.path.isdir(folder)
def generate_date_range(start_date, end_date):
"""
Generate a list of dates from start_date to end_date.
"""
return pd.date_range(start=start_date, end=end_date, freq='D').strftime('%Y%m%d').tolist()
def load_data(file_path):
"""
Load data from a NetCDF file.
"""
if os.path.exists(file_path):
return xr.open_dataset(file_path)
else:
raise FileNotFoundError(f'File not found: {file_path}')
# main program
## check data folder
data_folder = f'..\\..\\..\\surface_air_temperature\\data2024'
if check_data_folder(data_folder):
print(f'Data folder found: {data_folder}')
else:
raise FileNotFoundError(f'Data folder not found: {data_folder}')
## load data
start_date = '2024-01-01'
end_date = '2024-12-31'
date_list = generate_date_range(start_date, end_date)
## get location and shape
path = os.path.join(data_folder, f'M2T1NXFLX.5.12.4%3AMERRA2_400.tavg1_2d_flx_Nx.{date_list[0]}.nc4.dap.nc4')
nc4_data = load_data(path)
lat = nc4_data['lat'].values
lon = nc4_data['lon'].values
shape = nc4_data['TLML'].shape
total_locations = shape[1] * shape[2]
## combine data
sample_path = os.path.join(data_folder, f'M2T1NXFLX.5.12.4%3AMERRA2_400.tavg1_2d_flx_Nx.{date_list[0]}.nc4.dap.nc4')
sample_data = load_data(sample_path)
shape_per_file = sample_data['TLML'].shape
time_per_file = len(sample_data['time'])
total_samples = len(date_list)
combined = np.empty((total_samples * shape_per_file[0], *shape_per_file[1:]), dtype=np.float32)
time_list = np.empty(total_samples * time_per_file, dtype=sample_data['time'].dtype)
for i, date in enumerate(tqdm(date_list, desc="Combining")):
path = os.path.join(data_folder, f'M2T1NXFLX.5.12.4%3AMERRA2_400.tavg1_2d_flx_Nx.{date}.nc4.dap.nc4')
nc4_data = load_data(path)
start = i * shape_per_file[0]
end = (i + 1) * shape_per_file[0]
combined[start:end] = nc4_data['TLML'].values
time_list[start:end] = nc4_data['time'].values
print(f'Combined data shape: {combined.shape}')
## reshape data
locations = np.stack(np.meshgrid(lon, lat), axis=-1).reshape(-1, 2)
reshaped_data = combined.reshape(combined.shape[0], -1)
pd.DataFrame(reshaped_data) # 2d data with time as rows and locations as columns
reshaped_df = pd.DataFrame(reshaped_data, columns=[f"({lon}, {lat})" for lon, lat in locations], index=list(time_list))
time_num = len(time_list)
locations_num = len(locations)
## reshape data to (24, day, location) (24 hours)
reshaped_df.index = pd.to_datetime(reshaped_df.index)
groups = reshaped_df.groupby(reshaped_df.index.time)
stacked = np.stack([group.to_numpy() for time, group in sorted(groups)])
print(stacked)
time_order = sorted(groups.groups.keys())
print(time_order)
## train set
np.random.seed(123)
valid_mask = (locations[:, 0] >= 73) & (locations[:, 0] <= 104) & \
(locations[:, 1] >= 36) & (locations[:, 1] <= 54) # 緯度
valid_indices = np.where(valid_mask)[0]
day_num_train = 250
known_locations_num = valid_indices.shape[0] - 350 # 81.1%
unknown_locations_num = 350 # 18.9%
locations_num = known_locations_num + unknown_locations_num
locations_index = np.random.choice(valid_indices, size=locations_num, replace=False)
known_locations_index = locations_index[:known_locations_num]
unknown_locations_index = locations_index[known_locations_num:(known_locations_num + unknown_locations_num)]
known_locations_index.sort()
unknown_locations_index.sort()
known_locations_choose = locations[known_locations_index, :]
unknown_locations_choose = locations[unknown_locations_index, :]
stacked_train = stacked[:, :day_num_train, known_locations_index]
future_days = 10
known_real_data = stacked[:, :day_num_train + future_days, known_locations_index]
unknown_real_data = stacked[:, :day_num_train + future_days, unknown_locations_index]
print(f'Load data complete!')
# pip install u8darts[all]
from darts.models import TSMixerModel
from darts import TimeSeries
from datetime import datetime
from tqdm import tqdm
real_data = np.concatenate((known_real_data, unknown_real_data), axis=2)
locations_choose = np.concatenate((known_locations_choose, unknown_locations_choose), axis=0)
locations_index = np.concatenate((known_locations_index, unknown_locations_index), axis=0) # (1850,)
inference = np.array([[[0.0] * real_data.shape[2]] * future_days] * real_data.shape[0])
start_time = datetime.now()
for i in tqdm(range(real_data.shape[0])):
train_set = real_data[i, :day_num_train, :]
train_set = pd.DataFrame(train_set, index=pd.to_datetime(date_list[:day_num_train]), columns=[f"loc_{i}" for i in range(locations_num)])
train_set = TimeSeries.from_dataframe(train_set)
test_set = real_data[i, day_num_train:, :]
test_set = pd.DataFrame(test_set, index=pd.to_datetime(date_list[day_num_train:day_num_train + future_days]), columns=[f"loc_{i}" for i in range(locations_num)])
test_set = TimeSeries.from_dataframe(test_set)
model = TSMixerModel(
input_chunk_length=30,
output_chunk_length=10,
n_epochs=3800,
dropout=0.0005,
batch_size=32,
use_reversible_instance_norm=True,
random_state=42
)
model.fit(train_set)
forecast = model.predict(future_days)
inference[i] = forecast.values()
print(f'Inference complete! Time taken: {datetime.now() - start_time}')
y_true = real_data[:, day_num_train:, :]
y_pred = inference
mspe = np.mean(np.square(y_pred - y_true))
rmspe = np.sqrt(mspe)
mape = mspe = np.mean(np.abs(y_pred - y_true))
mspe_pct = np.mean(np.square(y_pred - y_true) / y_true)
rmspe_pct = np.sqrt(mspe_pct)
mape_pct = mspe_pct = np.mean(np.abs(y_pred - y_true) / y_true)
result_df = pd.DataFrame({
"Method": ["MSPE", "RMSPE", "MAPE", "MSPE%", "RMSPE%", "MAPE%"],
"Value": [mspe, rmspe, mape, mspe_pct, rmspe_pct, mape_pct]
})
print(result_df)
|
